2012 YAMAHA TTR50E pictures, review, features, specifications

2012 YAMAHA TT-R50E

Motorcycle pictures

2012 YAMAHA TT-R50E

Click Thumbnail to download (size 1600 x 1200 pixels)

2012 Yamaha TT-R50E Review

• Push button electric start and three-speed automatic transmission make this a great bike for learning.
• Turns rug rats into trail rats.
• Nothing makes learning more fun that a 2012 Yamaha TT-R50E. Chalk it up to the push button starter, monocross rear suspension and three-speed automatic clutch transmission and more.
• Our littlest Yamaha TT-R boasts big Yamaha YZ styling, four-stroke power, a three-speed automatic clutch gearbox - even push-button electric starting. Go ahead, play in the dirt.
• For the younger, smaller off-road fanatic in your family, look no further than the user-friendly TT-R50E.
• The 49cc four-stroke engine feeds power through a three-speed semi-automatic transmission, great for learning and playing. It's got the style of a big YZ, but low enough for the little guys to climb aboard with a seat that's only 555mm (21.9") above the ground. Once they're going, you'll be glad to know, the TT-R50E is equipped with front and rear drum brakes to deliver strong, dependable stopping power. Like all Yamaha's, TT-R's are packed full of leading-edge engineering and stand up to our stringent standards for reliability. They're built to last. The only thing we can't do is stop your little ones from out growing them! But we've got their next Yamaha waiting when that happens.

2012 Yamaha TT-R50E Features and Benefits

KEY POINTS
• 49cc, 4-stroke power
• Convenient Electric Starting
• Throttle Stop Screw

1. The TT-R50E gets the same pushbutton electric starting feature as our full line of electric-start TT-Rs.
2. Great for learning and/or playing, complete with 49cc of four-stroke fun feeding power through a three-speed automatic-clutch transmission.
3. Big YZ styling meets little people’s stature; the seat’s only 21.8 inches from the dirt.
4. Inverted fork and Monocross® rear end provide great handling.
5. Large chain cover for maximum protection and minimal maintenance.

ENGINE
• Air-cooled, 49.5cc, SOHC, 2-valve, 4-stroke powerplant produces smooth, reliable novice friendly power that eases the new rider up the learning curve.
• Convenient, push-button electric starting makes starting a snap and takes one of the hassles out of learning how to ride.
• Compact engine cases keep the engine narrow, making it easier for a smaller rider to get their feet firmly on the ground.
• Lightweight crankshaft design means crisp throttle response.
• The cylinder uses a conventional cast iron liner which means the engine can be overbored. The benefit is reduced costs in the event of a problem, plus the unit can be bored for adult pit bike use.
• Valve design features a special "carbon cutter" valve stem which helps to prevent the build up of carbon on the stem, which could cause a valve to stick. This is an important feature when a unit will be operated at sustained low speed and low rpms. Valve adjustments are via rocker arms for ease of maintenance.
• Automatic ratchet-type cam chain adjuster reduces maintenance, extends engine life and reduces mechanical noise.
• Mikuni VM11 carburetor ensures crisp throttle response and great fuel economy. It also features an electric carb heater for reduced engine warm-up time and faster cold starting (heater doesn't function above 16 degrees C or warmer). Carburetor features "Electroless" nickel plating applied to valve seat and nickel silver needle valve to counter act the negative effects of E10 (10% ethanol) fuels.
• Washable foam air filter reduces maintenance costs.
• Smooth-shifting, 3-speed transmission with automatic centrifugal clutch eases the beginner into the basics of shifting, without the complications of a hand operated clutch. The auto clutch means all the rider does is shift the foot pedal … there is no clutching involved.
• Transmission ratios have been designed to compliment the engine's power band.
• CDI ignition system delivers a hot, reliable spark, sure starts and requires no maintenance.
• Centrifugal oil filtering system is basically an automatic system that requires no maintenance.
• Lightweight, upswept exhaust system features numerous heat shields to protect young riders for hot components. This exhaust system produces a quiet exhaust note which will keep the neighbors happy. A cleanable screen-type spark arrestor protects Mother Nature from stray sparks.

CHASSIS / SUSPENSION
• Rugged "mini-size" steel back bone type frame provides rugged durability whether being ridden by a child or an adult. The engine mounts to the frame at three points, making the entire chassis more rigid for superior handling.
• Triangulated steel tube swingarm is both rugged and rigid.
• Inverted 22mm Showa front fork offers a class leading 96mm (3.8") of wheel travel providing confidence-inspiring control over rough terrain. The lower fork legs feature rugged plastic protectors that help to protect the fork legs from stone chips.
• Monocross single shock rear suspension with 71mm (2.8") of wheel travel delivers progressive suspension performance to smooth out rough trails.
• Low 556mm (21.9") seat height provides a handling-enhancing lower centre of gravity and allows most riders to put both feet firmly on the ground for added confidence.
• Long, motocross-style seat is low, comfortable and allows easy rider movements.
• Front and rear 80mm drum brakes deliver strong dependable stopping power. The brake design and components are the same front and rear.
• 2.50x10 front and rear knobby tires feature a 4 ply design, and offer superb traction in the dirt.
• 135mm (5.3") of ground clearance allows the TT-R50E to tackle modest obstacles.

DETAILS
• Rugged YZ-inspired plastic body components resist damage in the event of a tip-over. This design gives the TT-R50E that big YZ look while also creating a narrow profile for easy rider movements.
• Key operated, handlebar mounted ignition switch prevents joy rides when an adult supervisor is not present.
• Rugged YZ style handlebar features a re-enforcing cross bar for extra strength and a foam pad to protect the rider. YZ style grips give that big bike feel.
• Special sealed battery design is low-maintenance and prevents leakage even during a tip-over.
• Serrated steel folding footpegs provide excellent footing even in wet or muddy conditions.
• Convenient handlebar mounted paddle-style choke lever is easily accessible.
• On/off/reserve fuel petcock

SAFETY ITEMS
• Throttle stop screw allows parents or adult supervisor to control the top speed of the TT-R50E by restricting how far the throttle can be opened.
• Exhaust heat shields protect young riders from hot components
• Foam handlebar pad
• Keyed ignition allows parents to control use
• Upper and lower chain guards

IMPORTANT NOTE: Adult supervision and proper protective riding gear, including a helmet and eye protection are a must when a youngster is operating a TT-R50E.

USA Specifications/Technical Details
US MSRP Price: $1,390 (Team Yamaha Blue/White) Available from September, 2011

ENGINE
Type 49cc air-cooled SOHC 4-stroke; 2 valves
Bore x Stroke 36.0mm x 48.6mm
Compression Ratio 9.5:1
Fuel Delivery Mikuni® VM11
Ignition CDI
Transmission Constant-mesh 3-speed; automatic clutch
Final Drive Chain

CHASSIS
Suspension / Front Inverted telescopic fork; 3.8-in travel
Suspension / Rear Single shock; 2.8-in travel
Brakes / Front 80mm drum
Brakes / Rear 80mm drum
Tires / Front 2.50-10-4PR
Tires / Rear 2.50-10-4PR

DIMENSIONS
Length 51.4 in
Width 23.4 in
Height 30.5 in
Seat Height 21.8 in
Wheelbase 36.6 in
Ground Clearance 5.3 in
Fuel Capacity .82 gal
Wet Weight*** 125 lb

OTHER
Warranty 90 Day (Limited Factory Warranty)

2012 YAMAHA Raptor 700R ATV pictures, review, specs

2012 YAMAHA Raptor 700R

ATV pictures, review and specifications

2012 YAMAHA Raptor 700R

Click Thumbnail to download (size 1600 x 1200 pixels)

2012 Yamaha Raptor 700R Review

From the dunes to the trails, the 2012 Yamaha Raptor 700R is the undisputed big bore sport ATV performance leader. Featuring a fuel-injected 686cc, fully adjustable piggyback shocks, exclusive hybrid steel and aluminum frame, digital instrumentation and more.

We dare you to find a bigger wallop in a meaner package than the Raptor 700R.

Powered by our most potent big-bore Raptor engine ever—686cc of liquid-cooled fuel-injected power—this one will get your undivided attention. Maybe even more impressive is how sweet it is to ride: A thick comfortable seat, adjustable suspension, dual counterbalancers, electric starting and reverse keep things nice and civilized. Amazing performance wrapped in superb comfort, backed by Yamaha reliability. Any further questions? We rest our case.

Highlights

• 686cc of Liquid-Cooled Fuel-Injected Power

• Lightweight Hybrid Chassis

• Five-Way Adjustable Preload Kayaba Suspension

Key Features:

• A 686cc Yamaha fuel-injected engine makes this the most powerful Yamaha sport ATV ever, with big torque right off idle, transitioning into a fat mid-range and monstrous top end.

• Yamaha Fuel Injection (YFI) means consistently excellent engine performance in a wide range of conditions, elevations and temperatures.

• Reliable pushbutton electric start in any gear adds extra convenience.

• Race-bred five-speed transmission with reverse, along with Raptor 700R's monstrous powerband, means there's a choice of gears in just about all situations.

• Hybrid steel and aluminum frame with a Controlled-Fill aluminum sub frame and cast aluminum swingarm combine to produce a super-strong structure and the lightest ATV in its class.

• Long-travel suspension system features fully adjustable piggyback shocks with high- and low-speed compression damping for superior handling; rear shock adjusts for preload, rebound and compression damping.

• YFZ-inspired twin-aluminum-piston front disc brakes and rear disc deliver tremendous stopping power with less unsprung weight. The popular toggle link-type parking brake lever with an auto-adjust feature keeps maintenance to a minimum.

• Light, aluminum wheels mean less unsprung weight for great suspension action, and custom Dunlop radials provide maximum traction.

• Keep track of all systems with the trick and rugged LCD digital instrument meter: speed, rpm, coolant temp, etc.—it's all there.

• YFZ-spec 45mm serrated foot pegs provide excellent boot traction

• Krypton headlights set back in the front cowl add awesome sporting accent

• LED taillight provides great visibility

• Front brake master cylinder features an adjustable lever for increased comfort and feel

• Cast aluminum swingarm carries an eccentric quick-adjust drive chain mechanism that takes most of the work out of that task

• Aggressive styling reflects Raptor 700R's intent, and YFZ-inspired handling means it walks the walk, too.

• Long-travel suspension—9.1 inches front, 10.1 rear—a cushy seat and excellent ergonomics make the Raptor 700R comfortable to ride hard all day long.

Model not available in the USA

Canadian Specifications

Canadian MSRP* $10,799 CDN

Engine

Engine 4-stroke, SOHC, liquid-cooled, single

Displacement 686cc

Bore and Stroke 102 x 84mm

Compression Ratio 9.2:1

Carburetion Yamaha Fuel Injection (YFI), 44mm

Ignition 16 Bit ECU

Starting Electric

Transmission Wide-ratio 5-Speed Manual Clutch w/Reverse

Final Drive Sealed O-ring chain

Chassis

Suspension (Front) Independent double wishbone, 9.1" travel w/piggy back with high/low speed compression, rebound and threaded preload adjustment

Suspension (Rear) Cast aluminum swingarm, 10.1" travel w/piggy back with high/low speed compression, rebound and threaded preload adjustment

Brakes (Front) Dual Hydraulic Disc, Twin Piston Caliper

Brakes (Rear) Hydraulic Disc, Self Adjusting park Brake Function

Tires (Front) AT21x7-10 Radial

Tires (Rear) AT20x10-9 Radial

Dimensions

Length 1,845mm (72.6")

Width 1,170mm (46.1")

Height 1,130mm (44.5")

Wheelbase 1,280mm (50.4")

Ground Clearance 113mm (4.4")

Seat Height 815mm (32")

Wet Weight 192 kg (422 lb) - ready to ride full of fuel and oil

Fuel Capacity 11 litres

Colour(s) Yamaha Racing Blue

Specifications, appearance, and price of product are subject to change without notice.

2005 YAMAHA Raptor 660 ATV pictures, review and specs

2005 YAMAHA Raptor 660

ATV pictures, review and specifications

2005 YAMAHA Raptor 660

Click Thumbnail to download (size 1600 x 1200 pixels)

Let's Talk Torquey

Finesse is good, brute strength is often even better. That’s when you bust out the 660R Raptor.

Its big 660cc, liquid-cooled, five-valve SOHC engine starts laying down thick power right off idle and doesn’t let up until 9,000 rpm – the kind of instant power that gets you out of tight corners and up gnarly hills with authority.

The rest of the 660R Raptor is also built to thrive on abuse -

= New for 2005 - YFZ footpegs

= New for 2005 - Convenient parking brake

= Long-travel, adjustable suspension

= Strong yet lightweight frame

A comfortable YZ-style seat is up for aggressive riding or all-day cruising, while reverse and electric starting also conserve energy during those long days kicking trail.

The 2005 Special-Edition model adds a sportier, more menacing edge with a silver frame, dark grey bodywork with grey camo accents.

But we’re just getting warmed up here, so why don’t you visit the Features & Benefits page to get a closer look at the Raptor 660's list of incredible features.

The 660R Raptor. The competition just became extinct.

Specifications

MANUFACTURER Yamaha

MODEL YEAR 2005

MODEL 660R Raptor

M.S.R.P. * $6,199.00

DIMENSIONS

LENGTH 72.0 in.

HEIGHT 45.3 in.

WIDTH 43.3 in.

WEIGHT 398 lbs.

GROUND CLEARANCE 4.5 in.

WHEELBASE 49.0 in.

SEAT HEIGHT 33.9 in.

ENGINE

ENGINE 4-Stroke Single, 5-Valve SOHC

DISPLACEMENT 660 cc

BORE X STROKE 100 mm x 84 mm

COMPRESSION RATIO 9.2:1

CARBURETION Dual Mikuni 33 mm BSR

FUEL CAPACITY 3.2 gal.

IGNITION CDI

STARTING Electric

CLUTCH Manual

COOLING Liquid Cooled with Fan

DRIVETRAIN

TRANSMISSION 5-Speed with Reverse

DRIVE Sealed O-Ring Chain

BRAKES/WHEELS/TIRES

BRAKES Front: Dual Hydraulic Discs

Rear: Hydraulic Disc

TIRES Front: AT21 x 7-10 Radial

Rear: AT20 x 10-9 Radial

OPERATIONAL

SUSPENSION Front: Independent Double Wishbone, 9.1 in. w/ 5-way Preload Adjustment

Rear: Aluminum Swing Arm, 8.7 in. w/ Rebound, Compression and Threaded Preload Adjustment.

2011 YAMAHA Vino 50 / Vino Classic 50 pictures, review, specs

2011 YAMAHA Vino 50 / Vino Classic 50
Scooter pictures, review and specifications

2011 YAMAHA Vino 50 / Vino Classic 50

Click Thumbnail to download (size 1600 x 1200 pixels)

• The Euro-styled four-stroke for economical, practical, fun transportation.
• The stylish 2011 Yamaha Vino (Vino Classic 50 in the USA) offers clean, quiet, fuel efficient 4-stroke performance. The easy to ride 2011 Vino / 2011 Vino Classic makes more sense than ever as gas prices continue to spiral upwards. Fully automatic transmission, and locking under seat storage make the 2011 Yamaha Vino 50 / 2011 Yamaha Vino Classic 50 sensible fun loving alternative form of transport.
• A modern classic.
• The 2011 Vino Classic 50 / Vino 50 is what happens when you combine classic styling with modern engineering - an elegantly simple solution to the age-old problem of getting where you need to be with maximum efficiency and style - with a little joie de vivre thrown in for fun. Powered by a clean, reliable 49cc four-stroke engine that starts with the push of a button and gets great gas milage.
• The fashionable and fun loving Vino sports a clean, quiet, fuel efficient 4-stroke engine.
• The gas sipping Vino is ready to zip you around town with its environmentally friendly 49cc, 4-stroke powerplant. Whether you are looking for a fun, affordable way to commute or just looking to make a personal statement, the stylish 2011 Yamaha Vino 50 / 2011 Yamaha Vino Classic 50 may be the solution. Gas and go convenience meets European styling in the easy to ride, easy to own Vino.

2011 Yamaha Vino 50 / Vino Classic 50 model Features

• Fuel Consumption * 47kpl/132mpg(Imp)
• Clean and efficient 4-stroke power
• Under seat storage


ENGINE

• Peppy, 49cc, liquid-cooled (with fan assist), SOHC, 3-valve, 4-stroke engine puts out lively, predictable power with incredible gas mileage. The design concept of this engine is peppy performance with low noise, low emissions, and low fuel consumption.
• Fuel consumption of 47 kpl or 132 mpg. Your actual consumption may vary.
• Easy, dependable electric starting with backup kick starter.
• The cylinder features a ceramic composite coating which insures uniform heat dissipation, reduced friction and an extended service life.
• Three valve cylinder head design utilizes two intake valves (15.5mm) and one exhaust valve (16.5mm). The dual intake valves allow more fuel and oxygen to enter the engine for increased power output.
• Special "carbon cutter" valve design removes any carbon build-up on the valve stem to keep the engine operating at maximum efficiency, especially when the unit is being ridden at slow speed for prolonged periods of time.
• Roller rocker arms are used to actuate the valves. The roller rockers reduce friction and mechanical noise to a minimum for a quiet, enjoyable ride. Valve adjustment is via shims.
• Liquid-cooling with fan assist is used to maintain stable engine temperatures even during stop and go city riding. Liquid-cooling allows for a higher state of tune for increased engine performance. The radiator is positioned longiitually in the frame next to the engine.
• Crankcase sump-type oil delivery system is utilized. A special centrifugal oil filtering system is used. This type of oil "filter" automatically removes any particles found in the oil and never requires cleaning or maintenance.
• Keihin NCV18 carburetor features a throttle position sensor (TPS) that is linked to the ignition system to provide crisp throttle response. The TPS system monitors the throttle opening and sends the info to the CDI to provide the optimum ignition timing for great performance. Other TPS benefits include increased fuel economy and reduced emissions.
• Easy access, paper-type air filter is used. Total air box capacity is 2.0 liters for excellent performance and reduced intake noise.
• Automatic choke means no choke to fuss with and makes cold starting a snap.
• Fully automatic, V-belt centrifugal transmission ensures easy, twist-the-throttle-and-go operation. There is no clutch or gear shifting to worry about. A wide range reduction ratio is used for peppy performance.
• Maintenance-free CDI system with 2-D mapping provides a precise, high-voltage spark for fast starts and crisp engine performance at all rpms.
• Air induction system (AIS) is used to reduce harmful exhaust emissions. The AIS system injects oxygen into the exhaust port area to ensure complete fuel combustion, thereby reducing both hydrocarbon (HC) and carbon monoxide (CO) emissions.
• Exhaust system and muffler produce a very quiet environmentally friendly exhaust note. The muffler features a catalytic coating to further reduce harmful exhaust emissions.


CHASSIS/SUSPENSION

• Rugged, step-through, underbone-style, steel-tube frame design provides stable, predictable handling. The step-through design means it is very easy to get on and off the Vino.
• 26mm front fork provides a comfortable around town ride. Wheel travel is 65mm (2.6").
• Single-shock rear suspension provides a plush, comfortable ride. Wheel travel is 55mm (2.2").
• Front and rear 110mm drum brakes supply strong, reliable stopping power. They are hand operated, for ease of use …. just like on a bicycle !
• Rugged yet lightweight, die cast aluminum 5-spoke mag style wheels are fitted with 10" tubeless tires.
• Comfortable "saddle-type" single seat ensures excellent rider comfort and adds unmistakable style.
• Super convenient, large, 20 liter locking, under seat storage compartment can easily hold a full-face helmet or other items like a small briefcase or purse. Maximum capacity is 5 kilograms
• Large 4.5 liter fuel tank means lots and lots of kilometers between fill-ups. Locking fuel cap provides peace of mind.
• 35/35-watt multi-cut lens headlight maximizes nighttime visibility and enhances retro styling. The headlight and turn signals are chromed for an added styling highlight.
• Full-size floorboards and wide, stylish front apron provide excellent splash and wind protection and highlights that retro European styling.
• Eye catching, chromed speedometer assembly features an integrated electric fuel gauge. Large size digits are very easy to read. Other functions include high beam indicator light, turn signal indicator lights and coolant temperature warning light.
• Ultra convenient, key operated main ignition switch serves a number of purposes. Not only does it control the ignition, but is also opens the seat (including helmet storage), and locks the steering
• Unique "G-Lock" anti-theft rear wheel locking system. There is a small lever beside the ignition switch that when moved to the lock position, not only prevents the rear wheel from turning but also slides a cover over the key slot of the ignition switch. It is similar to shifting the transmission on an automatic car into park.
• Rugged chromed rear rack adds additional carrying capacity. Maximum capacity is 3 kgs.


ADDITIONAL FEATURES

• Electronic fuel gauge lets rider keep track of fuel level.
• Push-to-cancel-type turn signals enhance ease of use.
• Easy-to-use centre stand
• Low-maintenance, sealed battery
• Locking fuel cap and steering
• Heat shield on muffler
• Flexible turn signals that resist damage
• Front and rear side reflectors help maximize conspicuity in city traffic.
• Additional helmet or luggage hook near the ignition switch area
• High quality 3-D Vino logos on side covers
• Chromed headlight, turn signals and rear carrier


Specifications

MSRP: $2,250 (Seashell) Available from October 2010


Engine
Type 49cc liquid-cooled 4-stroke single, SOHC, 3 valve
Bore x Stroke 38.0mm x 43.5mm
Compression Ratio 12.0:1
Fuel Delivery Teikei 14mm
Ignition CDI
Transmission V-belt automatic
Final Drive V-belt



Chassis
Suspension / Front Telescopic fork, 2.3-in travel
Suspension / Rear Single shock, 2.1-in travel
Brakes / Front 110mm drum
Brakes / Rear 110mm drum
Tires / Front 90/90-10
Tires / Rear 90/90-10



Dimensions
Length 65.6 in
Width 24.8 in
Height 39.6 in
Seat Height 28.1 in
Wheelbase 45.7 in
Ground Clearance 3.3 in
Fuel Capacity 1.2 gal
Fuel Economy** 110 mpg
Wet Weight*** 178 lb



Other
Warranty 1 Year (Limited Factory Warranty)

2011 YAMAHA Zuma 50 pictures, scooter features, specifications

2011 YAMAHA Zuma 50

Scooter pictures, review and specifications

2011 YAMAHA Zuma 50

Click Thumbnail to download (size 1600 x 1200 pixels)

• The sporty Zuma is a fantastic combination of fun and practicality.

• Good things come in small packages.
• Back by popular demand, the sporty 2011 Yamaha Zuma 50 is a fantastic combination of fun and practicality. Think of it as a very trick scooter or a very small sport utility vechicle, the 2011 Yamaha Zuma's up for anything.

2011 Yamaha Zuma 50 model Features

Key Features:
• The sporty Zuma is a fantastic combination of fun and practicality.
• Carburetor settings and exhaust catalyzer technology reduce exhaust emissions.
• 49cc of reed-valve-inducted, Autolube-injected, two-stroke performance keeps the Zuma at the head of the 50cc pack.
• Fully automatic transmission and pushbutton electric starting make the Zuma super-convenient.
• There's room for two atop the Zuma's seat and lots of locking storage beneath it.
• The Zuma achieves fuel economy up to an estimated 123 mpg
* with a fuel tank that holds 1.5 gallons of gas.

Engine:
• Feisty 49cc, air-cooled two-stroke engine features a high 7.0:1 compression ratio for strong, usable power-perfect for around-town performance.
 • Reed-valve induction provides excellent throttle response and power delivery.
 • 14mm Teikei carburetor ensures seamless fuel delivery and crisp throttle response.
• Fan-assisted cooling system keeps engine temperature reliably under control, even while idling at stoplights, for maximum efficiency and longer engine life.
• Exclusive Autolube Oil Injection System ensures no mess or hassle of premixing fuel and oil.
• Easy-to-read indicator light located on instrument panel alerts rider when oil level gets low.
• Easy, dependable electric starting with backup kickstarter.
• Fully automatic V-belt transmission ensures easy, twist-the-throttle-and-go operation.
• DC-CDI system provides precise, high-voltage spark for seamless engine performance and excellent reliability.
• Automatic choke makes cold starting a cinch.

Chassis/Suspension:
• Step-through frame design allows easy mounting.
• Long wheelbase (50.2 inches) and large dimensions (74.4"L x 27.8"W x 43.7"H) enhance rider comfort with roomier ergonomics.
• Five-spoke cast wheels wear fat, low-profile 120/90-10 front and 130/90-10 rear tires that deliver tons of grip and attitude.
• Telescopic fork features beefy outer tubes for strength, while slider shrouds help protect inner tubes from debris.
• Telescopic front fork with 2.6 inches of travel smoothly soaks up what the road throws the rider's way.
• Single rear shock with 2.4 inches of travel ensures a plush ride quality in either solo or two-up mode.
" 155mm hydraulic front disc and rear drum brakes combine for serious stopping power.

Additional Features:
• Super-sporty styling and bodywork create a racy-looking package with an aggressive profile and riding position.
• Wide front apron and floorboards enhance Zuma's sporty profile while providing exceptional wind/weather protection and all-day comfort.
• Headlight system features dual bulbs with housings mounted atop the apron (vs. recessed) for great visibility and a sporty finish.
• Huge underseat storage compartment is perfect for hauling schoolbooks or groceries.
• Plush dual seat is long and wide for improved rider and passenger comfort.
• Sturdy rear cargo rack boasts a stainless finish and features extensions that double as passenger grabrails.
• Electronic fuel gauge lets rider easily keep track of gas level.
• Easy-to-read instrument panel features turn signal, high-beam and low-oil indicator lights.


Specifications
MSRP: $2,390 (Team Yamaha Blue/White) Available from October 2010


Engine
Type 49cc air-cooled 2-stroke single reed-valve inducted
Bore x Stroke 40.0mm x 39.2mm
Compression Ratio 7.0:1
Fuel Delivery 14mm Teikei
Ignition DC CDI
Transmission V-belt automatic
Final Drive V-belt


Chassis
Suspension / Front Telescopic fork; 2.6-in travel
Suspension / Rear Single shock; 2.4-in travel
Brakes / Front 155mm disc
Brakes / Rear Drum
Tires / Front 120/90-10
Tires / Rear 130/90-10


Dimensions
Length 74.4 in
Width 27.8 in
Height 43.7 in
Seat Height 30.1 in
Wheelbase 50.2 in
Ground Clearance 4.7 in
Fuel Capacity 1.5 gal
Fuel Economy** 123 mpg
Wet Weight*** 207 lb


Other
Warranty 1 Year (Limited Factory Warranty)

2012 YAMAHA Raptor 700R SE review, specifications, pictures

2012 YAMAHA Raptor 700R SE

ATV pictures, review and specifications

2012 YAMAHA Raptor 700R SE

Click Thumbnail to download (size 1600 x 1200 pixels)

2012 Yamaha Raptor 700R SE Review
There is no substitute
From the dunes to the trails, the 2012 Yamaha Raptor 700R SE is the undisputed big bore sport ATV performance leader. Featuring a fuel-injected 686cc, fully adjustable piggyback shocks, exclusive hybrid steel and aluminum frame, digital instrumentation and more.

We dare you to find a bigger wallop in a meaner package than the Raptor 700R.
Powered by our most potent big-bore Raptor engine ever—686cc of liquid-cooled fuel-injected power—this one will get your undivided attention. Maybe even more impressive is how sweet it is to ride: A thick comfortable seat, adjustable suspension, dual counterbalancers, electric starting and reverse keep things nice and civilized. The Raptor 700R Special Edition features all the same great characteristics as it's Raptor 700R brother, but comes with extras like Pro Armor Nerf Bars, Pro Armor Bumper, Pro Armor Radiator Cover , plus special graphics and colours. Big, broad power. Light weight. Precise handling. Yamaha reliability. That's the Yamaha advantage.

Highlights
• Pro Armor Nerf Bars
• Pro Armor Bumper
• Pro Armor Radiator Cover

Key Features:
• A 686cc Yamaha fuel-injected engine makes this the most powerful Yamaha sport ATV ever, with big torque right off idle, transitioning into a fat mid-range and monstrous top end.
• Yamaha Fuel Injection (YFI) means consistently excellent engine performance in a wide range of conditions, elevations and temperatures.• Reliable pushbutton electric start in any gear adds extra convenience.
• Race-bred five-speed transmission with reverse, along with Raptor 700R's monstrous powerband, means there's a choice of gears in just about all situations.
• Hybrid steel and aluminum frame with a Controlled-Fill aluminum sub frame and cast aluminum swingarm combine to produce a super-strong structure and the lightest ATV in its class.• Long-travel suspension system features fully adjustable piggyback shocks with high- and low-speed compression damping for superior handling; rear shock adjusts for preload, rebound and compression damping.
• YFZ-inspired twin-aluminum-piston front disc brakes and rear disc deliver tremendous stopping power with less unsprung weight. The popular toggle link-type parking brake lever with an auto-adjust feature keeps maintenance to a minimum.• Light, aluminum wheels mean less unsprung weight for great suspension action, and custom Dunlop radials provide maximum traction.
• Keep track of all systems with the trick and rugged LCD digital instrument meter: speed, rpm, coolant temp, etc.—it's all there.
• YFZ-spec 45mm serrated foot pegs provide excellent boot traction
• Krypton headlights set back in the front cowl add awesome sporting accent
• LED taillight provides great visibility
• Front brake master cylinder features an adjustable lever for increased comfort and feel
• Cast aluminum swingarm carries an eccentric quick-adjust drive chain mechanism that takes most of the work out of that task
• Aggressive styling reflects Raptor 700R's intent, and YFZ-inspired handling means it walks the walk, too.
• Long-travel suspension—9.1 inches front, 10.1 rear—a cushy seat and excellent ergonomics make the Raptor 700R comfortable to ride hard all day long.

Model not available in the USA

Canadian Specifications
Canadian MSRP* $11,149 CDN

Engine
Engine 4-stroke, SOHC, liquid-cooled, single
Displacement 686cc
Bore and Stroke 102 x 84mm
Compression Ratio 9.2:1
Carburetion Yamaha Fuel Injection (YFI), 44mm
Ignition 16 Bit ECU
Starting Electric
Transmission Wide-ratio 5-Speed Manual Clutch w/Reverse
Final Drive Sealed O-ring chain

Chassis
Suspension (Front) Independent double wishbone, 9.1" travel w/piggy back with high/low speed compression, rebound and threaded preload adjustment
Suspension (Rear) Cast aluminum swingarm, 10.1" travel w/piggy back with high/low speed compression, rebound and threaded preload adjustment
Brakes (Front) Dual Hydraulic Disc, Twin Piston Caliper
Brakes (Rear) Hydraulic Disc with wave style rotor and self adjusting parking brake function
Tires (Front) AT21x7-10 Radial
Tires (Rear) AT20x10-9 Radial

Dimensions
Length 1,845mm (72.6")
Width 1,170mm (46.1")
Height 1,130mm (44.5")
Wheelbase 1,280mm (50.4")
Ground Clearance 113mm (4.4")
Seat Height 815mm (32")
Wet Weight 192kg (422 lb)
Fuel Capacity 11 litres
Colour(s) Black

2012 YAMAHA FZ1 motorcycle pictures, review and specifications

2012 YAMAHA FZ1

Motorcycle pictures, review and specifications

2012 YAMAHA FZ1

Click Thumbnail to download (size 1600 x 1200 pixels)

2012 Yamaha FZ1 Review

Real-world performance that will make your everyday ride extraordinary.

The 2012 Yamaha FZ1 is a cutting edge sport bike with a twist. Unlike most other machines in this class, the 2012 FZ1 features state of the art engine and chassis designs. The twist is you don't have to sacrifice performance or handling to gain excellent rider and passenger comfort... the 2012 Yamaha FZ1 offers it all!

Crunch the numbers, do the math and then take a seat aboard one of the world's best "naked" sport bikes.

Surprisingly comfortable eh? You are looking at one of the best values in Yamaha's 2012 line-up. The FZ1 offers exceptional open class performance with cutting style. R1 inspired power, fuel injection, twin spar aluminum frame and fully adjustable suspension. The FZ1 is a serious sport bike that offers an exceptionally comfortable and exciting riding experience.

Think of the 2012 Yamaha FZ1 as an upright R1 ready to take on the world. There's more fuel-injected power in that smooth 20-vavle four-cylinder engine than most riders will ever use, in a sure-footed chassis. It's a rider's best ally, from track days to commuting to touring.


2012 Yamaha FZ1 Highlights and Key Features:
Fuel Consumption ± 15kpl/42mpg(Imp)
3rd generation fuel injected R1 powerplant
Serious sports focus with comfortable ergonomics

Key Features:
•Our ultimate street brawler brings 998cc of fuel-injected power to the fray, in a light-and-strong aluminum frame.
•Sculpted bodywork and a comfortable handlebar position for great looks and rider comfort.
•Adjustable suspension lets the FZ1 be dialed in for a wide range of uses—everything from urban assault to sport touring.

2012 Yamaha FZ1 Features and Benefits


ENGINE
Ultra-lightweight 998cc, DOHC, 20-valve, liquid-cooled, 40 degree inclined, in-line four-cylinder engine. The engine has been tuned to provide outstanding performance and excellent passing performance.

The crankcases, pistons, cylinder and cylinder head are based on the 3rd generation R1 powerplant ('04 to '06).

Combustion chamber design and squish area has been optimized for maximum sports performance. The compression ratio for the FZ1 is 11.5:1. Redline is set at 12,000 rpm and features a "soft" rev limiter to protect the engine.

Special lightweight, high lift, high performance intake and exhaust cams help to provide incredible horsepower and fast engine response. Cam profiles and the cam timing are designed to provide for more low to midrange power (Vs R1) .

Automatic cam chain tensioner reduces both maintenance and mechanical engine noise.

Lightweight, 3rd generation R1 based crankshaft provides quick engine response.

Connecting rods are carburized for strength and durability and use a nutless design. The lower end "cap" of the rod is made from the same piece of material as the upper portion, this design is known as "fracture splitting". This design aids in establishing true big end roundness and greater precision in con rod dimensions for great durability.

Closed deck cylinder design allows the cylinders to be spaced more closely together, allowing a narrower engine. The cylinder block is a stand-alone part. The benefit if this design is improved sealing, and easier serviceability.

Ceramic composite plated cylinder "bores" are a "liner less" design with the ceramic coating sprayed directly on the aluminum block to ensure great heat dissipation for consistent power delivery, reduced friction and reduced weight.

Short skirt, lightweight forged pistons reduce mechanical vibration and improve throttle response.

3rd generation R1 inspired "stacked" 3-axis gearbox / clutch design stacks input/output shafts to create a low center of gravity and keeps overall engine size shorter front to back. As a result, the stacked design gives the engineers the freedom to place the engine in the frame for optimum front to rear weight balance and thereby maximizing handling

Smooth shifting 6-speed transmission features optimized gear ratios for maximum performance in the "real world". 5th and 6th ratios are wider (taller) for reduced engine rpms at highway speeds for more relaxed cruising.

Compact, heavy duty, multi-plate clutch ensures consistent, positive engagement and uses coil springs (5) and paper based fiber plates (9) to reduce weight.

Mikuni fuel injection system is based on the 2006 R1 design, featuring 45mm throttle bodies fitted with T.P.S. (Throttle Position Sensor). This style of fuel injection uses dual throttle valves. The secondary or sub throttle valves are motor driven and control the intake air volume for optimum throttle response.

The actual injectors are Denso "long nose" type injectors with a high dynamic range and 4-spray holes for excellent power and response across the entire rev range.

Specially designed 8.2-liter air box with intake air temperature sensor maximizes performance. A viscous paper-type air filter is utilized.

The fuel injection's lightweight Electronic Control Unit (ECU) utilizes a powerful 32-bit processor for faster control of the injection process. The compact design also reduces weight.

Yamaha's patented Exhaust Ultimate Power Valve (EXUP) monitors engine rpm and adjusts exhaust flow for maximum performance at all rpms with no flat spots. This system also optimizes fuel economy and reduces emissions.

4 into 2 into 1 exhaust system features stainless steel exhaust pipes and a short design silencer / muffler. The header pipe length has been optimized for maximum power delivery. This system is fitted with two 3-way honeycomb catalyziers with an oxygen sensor to reduce harmful CO and HC exhaust emissions.

High-efficiency curved radiator features compact dual ring-type fans for maximum cooling efficiency. This rad and fan design produces more airflow than conventional flat design rads to maintain optimum engine temperatures for consistent power output. The curved design also allows a shorter wheelbase.

Large, liquid-cooled oil cooler maintains stable lubricant temperatures for extended engine life. Convenient spin-off oil filter is used.

Convenient clutch cover sightglass ensures easy oil level inspection.

Maintenance-free transistor-controlled ignition ensures great performance at all rpms.

Air Induction System (AIS … not ram air) reduces harmful HC and CO exhaust emissions for a cleaner environment.

CHASSIS / SUSPENSION
Die cast lightweight aluminum twin spar frame provides an optimized rigidity balance for incredible sports handling. The engine is a stressed member of the chassis, allowing a lighter main frame design without sacrificing stability and light, agile handling qualities.

The riding position which is one of the most important features of the FZ1, it offers a balance between a sporty riding position and great rider comfort.

Key chassis geometry figures include: 51% front and 49 % rear weight balance, 25 degrees of rake and 109 mm of trail. The 47 degree lean angle highlights the FZ1 sporty side.

Lightweight, detachable rear sub frame allows easy access to rear suspension components and reduces costs in the event of a "loop-out".

C.F. (Controlled Filling) die cast truss-type rear swingarm offers great rear wheel control and traction for razor-sharp cornering and superb stability at speed. The long 629mm arm helps to minimize the effect of "chain tensioning" on the bike's handling.

43mm Kayaba inverted cartridge style fork is fully adjustable and offers 130mm (5.1") of wheel travel. This fork features independent damping adjustments for compression and rebound via a one way port that separates the two functions. Adjustments include: 9-way spring preload, 26-way compression damping and 26-way rebound damping. The adjustable design allows the rider to tailor suspension settings to match rider weight and road /track conditions to maximize handling and suspension performance.

Lightweight aluminum upper triple clamp features a 25mm offset for sportier handling.

Link-type Monocross rear suspension features an adjustable Kayaba shock that allows the rider to tailor suspension settings to match load and road conditions. Adjustments include 7 - way spring preload, and 12-way rebound damping. Rear wheel travel is 130mm or 5.1"

320mm dual front discs are squeezed by ultra rigid R6 inspired monoblock, 4-piston calipers which provide outstanding stopping power and lever feedback. The master cylinder utilizes 16mm piston for outstanding stopping power with less lever effort.

245mm rear disc is squeezed by a lightweight single piston slide-type Nissin caliper with sintered metal brake pads.

Lightweight cast-aluminum 5-spoke wheels reduce unsprung weight for great handling characteristics. The front wheel is an MT3.50-17 and is fitted with competition-spec 120/70-ZR17 tire, while the rear wheel is a MT6.00-17 fitted with a wide 190/50-ZR17 rear radial.

Eye catching, half fairing offers surprisingly good wind and weather protection. It features R1 inspired dual "cat eye" halogen headlights.

Conventional handlebar design features a more upright positioning for maximum everyday comfort. Handlebar is mounted above the top triple clamp.

18-liter fuel tank offers a slim design with great knee grip. The reserve portion of the tank is 3.4 litres.

Separate rider and passenger seats offers exceptional solo or two-up comfort.

One-piece instrumentation features analog tachometer, digital speedometer, dual tripmeters, fuel gauge, clock and new outside air temperature display. The back lighting on the instrument can be adjusted to suit the rider's preference.


ADDITIONAL DETAILS / FEATURES
Low fuel warning light
Integrated passenger grab rails
Adjustable, 5-position front brake lever
Durable "O" ring-sealed drive chain
Lightweight, sealed low-maintenance battery
Excessive lean angle engine cut-out switch.
Lockable steering
The FZ1 offers a significant level of power and performance. It is not intended for novice or inexperienced riders.

Specifications
MSRP* $10,590 (Pearl White/Matte Black) Available from February 2012

ENGINE
Type 998cc liquid-cooled inline 4-cylinder; DOHC, 20 valves
Bore x Stroke 77 x 53.6mm
Compression Ratio 11.5:1
Fuel Delivery Fuel injection
Ignition Digital TCI: Transistor Controlled Ignition with 32-bit ECU
Transmission 6-speed w/multiplate clutch
Final Drive O-ring chain

CHASSIS
Suspension / Front 43mm fork; fully adjustable, 5.1-in travel
Suspension / Rear Single shock; adjustable preload and rebound damping, 5.1-in travel
Brakes / Front Dual 320mm floating discs w/4-piston calipers
Brakes / Rear 245mm disc w/single-piston caliper
Tires / Front 120/70-ZR17
Tires / Rear 190/50-ZR17

DIMENSIONS
Length 84.3 in
Width 30.3 in
Height 47.4 in
Seat Height 32.1 in
Wheelbase 57.5 in
Ground Clearance 5.3 in
Rake (Caster Angle) 25.0°
Trail 4.3 in
Fuel Capacity 4.8 gal
Fuel Economy** 35 mpg
Wet Weight*** 487 lb

OTHER
Warranty 1 Year (Limited Factory Warranty)

2012 YAMAHA TT-R110E motorcycle pictures and specifications.

2012 YAMAHA TT-R110E

Motorcycle pictures

2012 YAMAHA TT-R110E

Click Thumbnail to download (size 1600 x 1200 pixels)

2012 Yamaha TT-R110E Review

• Big fun for the whole family, the all-new TT-R110 begs to be ridden by everyone from bigger kids to adults.

• Pure off-road fun.

• Torquey 110cc air-cooled 4-stroke engine, 4-speed gearbox with automatic clutch and effortless starter. The only drawback? Only one family member can ride at a time. Better get a few.

• Spark your kids 2-wheel passion with a 2012 Yamaha TT-R110E! Learning is a snap with electric start, smooth power delivery and lightweight design.

• Yamaha's TT-R110E is intended for kids, but as you'll soon find out, adults can't resist jumping on it as well!

• It's no surprise, as the 4-speed, clutchless, smooth revving 110E is so simple and straightforward to ride. Electric start comes standard, as does Yamaha's legendary reliability.

IMPORTANT NOTE: Adult supervision and proper protective riding gear, including a helmet, are a must when a youngster is operating a TT-R110E.

2012 Yamaha TT-R110E Features and Benefits

KEY POINTS

• Electric Start

• Automatic Clutch

• Reliable 4-stroke Engine

• Convenient electric starter for effortless starting.

• Big fun for the whole family, the YZ-styled, four-stroke-powered TT-R110 begs to be ridden by everyone.

• A seat height of only 26.4 inches makes this one accessible to most riders, but 7.1 inches of ground clearance and great suspension at both ends means it can go places.

• Four-speed auto-clutch transmission has an easily accessible gear for nearly any terrain.

• To see the complete line of GYTR® accessories for the TT-R110E, check out the 2011 Spring Big Book.

ENGINE

• Air-cooled, 110cc, SOHC, 2-valve, 4-stroke powerplant produces smooth, reliable, novice friendly power.

• Convenient, push-button electric starting backed up by a manual kick starter too. Starting the TT-R110E could not be easier!

• Lightweight aluminum cylinder features a cast iron liner. It can be "bored out" in the event of a problem.

• Single overhead camshaft utilizing easy to adjust conventional rocker arms

• Flat top piston provides a 9.3:1 compression ratio and produces plenty of torque for easy to use power.

• Lightweight crankshaft design means fast throttle response.

Automatic cam chain adjuster reduces maintenance, extends engine life and reduces • mechanical noise.

• 16mm Mikuni carburetor ensures crisp throttle response and great fuel economy. Carburetor features nickel silver needle valve assembly and chromate treatment on the inner float bowl to counter act the negative effects of E10 (10% ethanol) fuels.

• 4-speed, semi-automatic transmission (featuring an automatic centrifugal multi plate clutch) eases the beginner into the basics of shifting, without the complications of a standard hand operated clutch.

• CDI ignition system delivers a hot, reliable spark, fast sure starts and requires no maintenance.

• Easy access washable foam air filter reduces maintenance costs.

• Lightweight, exhaust system is quiet and comes equipped with a cleanable screen-type spark arrestor to protect Mother Nature. Heat shields protect young riders from hot components. Sound levels will keep the neighbors smiling.

• Rugged steel engine protector plate for those rough trails.

CHASSIS / SUSPENSION

• "Mid size" steel "backbone-type" frame features a compact 1080mm (42.5") wheelbase for easy, agile handling with a low, confidence inspiring seat height. The perfect combination for young aspiring riders.

• Triangulated steel swingarm is both rugged and rigid.

• Leading axle 31mm hydraulic front fork offers 115mm (4.5") of wheel travel providing confidence-inspiring control over bumpy terrain.

• Die-cast aluminum upper triple clamp highlights this machine's big bike features and quality.

• Monocross single shock rear suspension offers 110mm (4.3") of wheel travel. The gas pressurized shock delivers progressive suspension performance to smooth out rough trails.

• 670mm (26.4") seat height allows most riders to put both feet firmly on the ground for added confidence.

• Flat motocross-style seat provides great rider comfortable and allows easy rider movements. The seat cover features a "gripper design" … just like our full sized YZ motocrossers.

• Front and rear drum brakes deliver strong dependable stopping power.

• Rugged steel rims fitted with knobby tires offer superb grip in the dirt.

• 3.8 litre black plastic fuel tank highlights the TT-R110E's YZ heritage.

• 180mm (7.1") of ground clearance provides lots of clearance for serious trail riding.

DETAILS

• Rugged YZ-inspired plastic body components resist damage in the event of a tip-over.

• Team Yamaha-inspired colour and graphics, plus front and side number plates create styling almost identical to Yamaha's legendary YZ motocrossers.

• Handlebar-mounted, key-operated ignition switch prevents unwanted joy rides and allows parents to control usage.

• Special sealed battery design is low-maintenance and prevents leakage even during a tip-over.

• Serrated steel folding foot pegs provide excellent grip even in wet or muddy conditions.

• Handlebar with reinforcing crossbar and protective foam pad

• Upper and lower plastic chain guards reduce chain splatter and protect young riders.

• Easy access paddle-style choke

• On/off/reserve fuel petcock

• Front and rear reflectors for added visibility

IMPORTANT NOTE: Adult supervision, a helmet and proper protective riding gear are a must when a youngster is operating a TT-R110E.

USA Specifications

US MSRP Price: $2,190 (Team Yamaha Blue/White) Available from August, 2011

ENGINE

Type 110cc air-cooled 4-stroke, SOHC

Bore x Stroke 51.0mm x 54.0mm

Compression Ratio 9.3:1

Fuel Delivery Mikuni® VM16

Ignition CDI

Transmission Constant-mesh 4-speed/wet, multiple disc

Final Drive Chain drive

CHASSIS

Suspension / Front Telescopic fork, coil spring/oil damper, 4.5-in travel

Suspension / Rear Swingarm Monocross®, coil spring/gas-oil damper, 4.3-in travel

Brakes / Front 95mm drum

Brakes / Rear 110mm drum

Tires / Front 2.50-14-4PR

Tires / Rear 3.00-12-4PR

DIMENSIONS

Length 61.6 in

Width 26.8 in

Height 36.3 in

Seat Height 26.4 in

Wheelbase 42.5 in

Ground Clearance 7.1 in

Fuel Capacity 1.0 gal

Wet Weight*** 158 lb

OTHER

Warranty 90 Day (Limited Factory Warranty)
